TSD / Hammer fixing

Hammer fixing TSD

TSD - with zinc plated steel nail

Characteristics

• Fixing system consisting of expansion plug with retaining disc and expansion nail with special head
• Special head type prevents unnecessary leakage of heat and offers additional corrosion protection
• The special disc profile allows optimum adhesion of plaster
• Pre-assembled units for reduced installation efforts with European Technical Approval as multiple
• Fixing of glued composite insulation systems acc. to ETAG 004

Suitability

• Base materials: concrete, natural stone, solid brick, limited suitability for hollow brick, hollow block, aircrete
• For fixing of: various types of insulation material, good plaster adhesion (ex.: for composite insulation systems)

Advice

The drill hole must be cleaned with brush and air pump. As existing render/ plaster may not be considered as base material a longer plug as well as a correspondingly deeper drill hole are required
