ALB / Base profile with mesh and hidden drip edge

Base Profile with Mesh and Hidden Drip Edge for ETICS

The Base Profile with Mesh and Hidden Drip Edge is designed to form clean horizontal transitions where insulation materials of different thicknesses meet in ETICS systems.

It includes an integrated glass fiber mesh and a concealed drip edge for controlled water runoff and a neat finished appearance. The profile is suitable for an external plaster layer with a total thickness of 6 mm, including the base coat and finishing coat.

Features:

• Base profile with integrated mesh

• Hidden drip edge

• Designed for ETICS thermal insulation systems

• Suitable for horizontal transitions between different insulation thicknesses

• Intended for a 6 mm external plaster layer

• UV-stabilized PVC

• Resistant to alkaline environments

• Glass fiber mesh compliant with ETAG 004

• Supports a clean and concealed finishing detail

• Helps direct water away from the facade

Installation instructions:

1. Insert the profile into the narrow horizontal gap between insulation materials of different thicknesses.

2. Apply the base coat to the width of the integrated glass fiber mesh.

3. Embed the mesh into the base coat.

4. Smooth the mesh using a stainless steel trowel.

5. Finish the full-surface reinforcement at the folded edge of the profile.

6. Maintain a minimum overlap of 100 mm between insulation joints, profiles, and glass fiber mesh.

7. Use cutting discs suitable for hard PVC when shortening the profile.

8. Install the profile and complete the ETICS base layer in one working cycle.

9. Follow the project documentation and the installation instructions provided by the ETICS system manufacturer.

Storage:

• Store horizontally

• Keep in a dry place

• Storage temperature: -5°C to +40°C

• Maximum recommended storage time: 24 months
